High Breaking Capacity for Critical System Protection
Our HV HRC Fuse delivers exceptional breaking capacity for demanding applications. This product covers voltage levels from 10kV to 40.5kV. It provides short-circuit protection for high-capacity power systems. The product uses a high-capacity current-limiting structure design. The fuse element consists of multiple parallel high-purity silver strips. This design provides very low resistance and power loss during normal operation. During a fault, all silver strips melt simultaneously and uniformly. This coordinated melting maximizes the quartz sand arc-absorption capability. The fuse offers high-speed interruption and current limitation. It limits short-circuit current to levels far below the expected peak. This reduces electromagnetic and thermal damage to transformers and busbars. The product has an ultimate breaking current of 63kA or higher. This rating far exceeds standard fuse capabilities. It meets the protection needs of main transformers and high-voltage busbars.
Reliable Performance for Critical Locations
This HV HRC Fuse is designed for critical system locations. It protects main transformers at large industrial substations. It also protects high-voltage busbars where faults have huge energy levels. The product performs reliably even during severe metallic short circuits. These events can produce fault currents of tens of kiloamperes. Our fuse clears these faults quickly and safely. The product's special fuse element design ensures consistent performance. The silver strips are manufactured to tight tolerances. This ensures coordinated melting during fault events. The high-purity quartz sand filling improves arc-absorption efficiency. This material choice enables the high breaking capacity rating. Each fuse element is carefully assembled to ensure proper placement. The assembly process is controlled and documented thoroughly. Our manufacturing consistency gives you reliable protection every time. The fuse has been tested to verify its high breaking capacity. These tests confirm safety and effectiveness under extreme fault conditions.
Testing Support and Selection Assistance
Our HV HRC Fuse comes with comprehensive factory test reports. Each product receives DC resistance measurement before shipment. We also verify fusing characteristics through sample testing. These tests confirm performance against design specifications. We provide a 12-month warranty from the delivery date. Our technical team helps with application-specific selection calculations. We determine the correct fuse rating for your system's short-circuit capacity. This service ensures optimal protection and coordination. The product is ideal for main circuit protection in medium-voltage systems. Its high breaking capacity provides the highest level of fault protection. The fuse's fast operation reduces stress on other system components. This extends the service life of transformers and switchgear. Choose our HV HRC Fuse for the highest level of short-circuit protection in your critical power circuits.
Product Parameters
|
Parameter |
Value |
|
Product Series |
XRNT-H Series |
|
Voltage Ratings |
10kV - 40.5kV |
|
Ultimate Breaking Current |
≥63kA |
|
Structure Type |
High-Capacity Current-Limiting Structure |
|
Typical Application |
Main Transformer Protection, High-Voltage Busbar Protection |
|
Warranty Period |
12 months from delivery date |
